Description
| Model |
DQ4113 |
DQ4116/DQ4119 |
| Max. Drilling capacity (mm) |
13 |
16/19 |
| Diameter of column (mm) |
70 |
70 |
| Spindle travel (mm) |
85 |
85 |
| Distance spindle axis to column generating line (mm) |
180 |
180 |
| Max. Distance spindle nose to table (mm) |
390 |
410 |
| Max. Distance spindle nose to base (mm) |
570 |
590 |
| Spindle taper |
B16 |
MT2 |
| Spindle speeds range (r/min) |
450-2650 |
200-2780 |
| Spindle speeds series |
4 |
12 |
| Dimension of worktable surface (mm) |
240 X 240 |
240 X 240 |
| Dimension of base (mm) |
445 X 270 |
445 X 270 |
| Overall height (mm) |
960 |
960 |
| Motor (KW) |
0.37 |
0.37/0.55 |
| G.W/N.W (kg) |
68/65 |
68/65 |
| Packing dimension (cm) |
91 X 51.5 X 27 |
91 X 51.5 X 27 |
PURROS Machinery have various types of Hydro Speed Regulators, Self-Feeding Drill Heads(Units), Multi-Spindle Drill Heads and Servo feed tapping machine, Special Purpose Machines, warmly waiting for you to inquire.
