Distance spindle axis to column generating line (mm)
360
Max. Distance spindle nose to table (mm)
590
Max. Distance spindle nose to base (mm)
1180
Spindle taper
MT4
Spindle speeds range (r/min)
42-2050
Spindle speeds series
12
Spindle feeds (mm/r)
0.07、0.15、0.26、0.40
Dimension of worktable surface (mm)
550 X 470
Table travel (mm)
550
Dimension of base table (mm)
450 X 440
Overall height (mm)
2330
Main motor (KW)
2.2/2.8
Coolant motor (W)
40
G.W/N.W (kg)
750/680
Packing dimension (cm)
108 X 62 X 245
PURROS Machinery have various types of Hydro Speed Regulators, Self-Feeding Drill Heads(Units), Multi-Spindle Drill Heads and Servo feed tapping machine, Special Purpose Machines, warmly waiting for you to inquire.
