Distance spindle axis to column generating line (mm)
183
Max. Distance spindle nose to table (mm)
485
Max. Distance spindle nose to base (mm)
660
Spindle taper
B18
Spindle speeds range (r/min)
240、380、570
Spindle speeds series
3
Dimension of base (mm)
270 X 280
Spindle box travel (mm)
520 X 310
Overall height (mm)
1220
Power of main motor (KW)
0.55/0.75
G.W/N.W (kg)
120/102
Packing dimension (cm)
70 X 44 X 128
PURROS Machinery have various types of Hydro Speed Regulators, Self-Feeding Drill Heads(Units), Multi-Spindle Drill Heads and Servo feed tapping machine, Special Purpose Machines, warmly waiting for you to inquire.
